Bonding, laminating, lacquering
Casting, printing, and more
Mobile extraction device for variable and flexible operating conditions
High extraction performance, stepless adjustment
Extremely quiet operation
Easy filter handling, access via suction plate
ABS Material (impact-resistant, chemical-resistant, corrosion-resistant)
Fitting for extraction arms (Ø 50/75) and collection elements typical for your application
|Device version||JUMBO Filtertrolley 2.0 ACD|
|Max. flow rate in m³/h||190|
|Max. flow rate in cfm||112|
|Max. vacuum in Pa||3200|
|Max. vacuum in inch wc||12.9|
|Nominal capacity in m³/h@Pa||80 @ 1900|
|Nominal capacity in cfm@inch wc||47 @ 7.6|
|Dimensions in mm (WxDxH)||450x340x530|
|Dimensions in inch (WxDxH)||17.8x13.4x23.6|
|Weight in kg||36|
|Weight in lbs||79|
|Noise level in dB||49|
|Connection variants – diameter in mm||1 X 50 / option: 1 X 75|
|Connection variants – diameter in inch||1 X 1.97 / option: 1 X 2.95|
ULT’s extraction and filtration systems are especially quiet. This is appreciated by numerous clients worldwide. This means your employees won’t be bothered by unnecessary noise.
Many of the ULT fume extraction systems can be utilized flexibly. For example, you can choose between mobile or stationary systems, device integrations or special ventilation solutions. If necessary, the ideal application is configured by ULT experts on-site.
ULT’s extraction and filtration systems are designed so that they can be put into operation without problems and easily used. Should there be any questions, our service technicians would be happy to assist you at any time.
Low energy requirements
ULT’s extraction systems reduce the operation and maintenance costs based on your optimal filtration plan. In addition, the system is designed so that the required energy consumption is kept very low.
Optimal filter technology
Using the most sensible filtration technology ensures a long filter service life and, consequently, reduces the costs of maintenance and spare parts. ULT always offers you the optimal solution for your special contaminant technology to achieve the best filtration possible..
Individual extraction solution
Your systems will be adapted to your needs. Starting with the pollutant situation and your internal processes to the best possible collection solution - we advise and support you in the selection and installation of your ideal extraction and filtration solution.
